node:AddInput("src", img) node:AddOutput("dst", out)
success = node:RunSession(req)
-- Registry declaration
FuRegisterClass("GPUSampleFuse", CT_SourceTool, { REGS_Category = "Fuses\\Examples", REGS_OpIconString = "GFu",
REGS_OpDescription = "GPU Sample Fuse",
REG_NoObjMatCtrls = true, REG_NoMotionBlurCtrls = true,
REG_Source_GlobalCtrls = true, REG_Source_SizeCtrls = true, REG_Source_AspectCtrls = true, REG_Source_DepthCtrls = true,
})
-- Description of kernel parameters GradientParams = [[
float col[4]; int dstsize[2];
]]
CircleParams = [[ float amp; float damp; float freq; float phase; float center[2]; int srcsize[2]; int compOrder;
]]
-- source of kernel
GradientSource = [[
KERNEL void GradientKernel( CONSTANTREF GradientParams *params,
TEXTURE2D_WRITE dst)
{
DEFINE_KERNEL_ITERATORS_XY(x, y)
if (x < params->dstsize[0] && y < params->dstsize[1])
{
float2 pos = to_float2(x, y) / to_float2(params->dstsize[0] - 1, params->dstsize[1] - 1);
float4 col = to_float4_v(params->col); col *= to_float4(pos.x, pos.y, 0.0f, 1.0f);
_tex2DVec4Write(dst, x, y, col); // image, x, y, float4 color
}
}
]]
CircleSource = [[
#define _length(a,b) _sqrtf(((a).x-(b).x)*((a).x-(b).x) + ((a).y-(b).y)*((a).y- (b).y))
KERNEL void CircleKernel( CONSTANTREF CircleParams *params,
TEXTURE2D src, TEXTURE2D_WRITE dst)
{
DEFINE_KERNEL_ITERATORS_XY(x, y)
if (x < params->srcsize[0] && y < params->srcsize[1])
{
float2 pos = to_float2(x, y) / to_float2(params->srcsize[0] - 1, params->srcsize[1] - 1);
float2 center = to_float2_v(params->center); float d = _length(pos, center);
float vl = fmax(params->amp - params->damp * d, 0.0f); vl = 1.0f + sin(d * params->freq + params->phase) * vl;
float2 frompos = vl * (pos - center) + center;
// source image, x & y coords, component mask
float4 col = _tex2DVecN(src, frompos.x, frompos.y, params-
>compOrder);_tex2DVec4Write(dst, x, y, col);
}
}
]]
function Create()
InCenter = self:AddInput("Center", "Center", { LINKID_DataType = "Point", INPID_InputControl = "OffsetControl", INPID_PreviewControl = "CrosshairControl",
})
InAmplitude = self:AddInput("Amplitude", "Amplitude", { LINKID_DataType = "Number",
INPID_InputControl = "SliderControl", INP_Default = 0.5,
})
InDamping = self:AddInput("Damping", "Damping", { LINKID_DataType = "Number", INPID_InputControl = "SliderControl", INP_Default = 0.0,
})
InFrequency = self:AddInput("Frequency", "Frequency", { LINKID_DataType = "Number",
INPID_InputControl = "SliderControl", INP_Default = 20,
INP_MaxScale = 100.0,
})
InPhase = self:AddInput("Phase", "Phase", { LINKID_DataType = "Number", INPID_InputControl = "ScrewControl", INP_Default = 0.0,
INP_MaxScale = 10.0,
})
-- OutImage is automatically created for us, as we’re a CT_SourceTool
end
function Process(req)
local center = InCenter:GetValue(req) local amp = InAmplitude:GetValue(req).Value local damp = InDamping:GetValue(req).Value local freq = InFrequency:GetValue(req).Value local phase = InPhase:GetValue(req).Value
local realwidth = Width; local realheight = Height;
-- We’ll handle proxy ourselves Width = Width / Scale
Height = Height / Scale Scale = 1
local imgattrs = {
IMG_Document = self.Comp, IMG_Width = Width, IMG_Height = Height, IMG_XScale = XAspect, IMG_YScale = YAspect,
IMAT_OriginalWidth = realwidth, IMAT_OriginalHeight = realheight, IMG_Quality = not req:IsQuick(),
IMG_MotionBlurQuality = not req:IsNoMotionBlur(),
}
if not req:IsStampOnly() then imgattrs.IMG_ProxyScale = 1
end
if SourceDepth ~= 0 then imgattrs.IMG_Depth = SourceDepth
end
local img = Image(imgattrs) local out
local success = false if img then
local node = DVIPComputeNode(req, "GradientKernel", GradientSource, "GradientParams", GradientParams)
if node then
-- create image
local params = node:GetParamBlock(GradientParams)
params.col[0] | = | 1.0 |
params.col[1] | = | 1.0 |
params.col[2] | = | 1.0 |
params.col[3] | = | 1.0 |
params.dstsize[0] = img.DataWindow:Width() params.dstsize[1] = img.DataWindow:Height()
node:SetParamBlock(params) node:AddOutput("dst", img)
success = node:RunSession(req)
end
-- and warp it if success then
out = Image({IMG_Like = img })
local node = DVIPComputeNode(req, "CircleKernel", CircleSource, “CircleParams", CircleParams)
if node then
-- create image
local params = node:GetParamBlock(CircleParams)
params.amp = amp params.damp = damp params.freq = freq params.phase = phase params.center[0] = center.X params.center[1] = center.Y params.compOrder = 15
params.srcsize[0] = out.DataWindow:Width() params.srcsize[1] = out.DataWindow:Height()
node:SetParamBlock(params)
node:AddSampler("RowSampler", TEX_FILTER_MODE_ LINEAR, TEX_ADDRESS_MODE_CLAMP, TEX_NORMALIZED_ COORDS_TRUE)
node:AddInput("src", img) node:AddOutput("dst", out)
success = node:RunSession(req)
else
out = nil
end
end
end
OutImage:Set(req, out)
end
