Control Types

The following table indicate types of control.

Text	Displays the Fusion textedit control, which is used to enter large amounts of text into a control.	Linear (integer) A number specifying how many lines of text to display in the control. Wrap (boolean) A true or false value that determines whether the text entered into the control will wrap to the next line when it reaches the end of the line. ReadOnly (boolean) If this option is set to true, the control will not allow any editing of the text within the control. Used for displaying non-editable information. FontName (string) The name of a truetype font to use when displaying text in this control. FontSize (numeric) A number specifying the font size used to display the text in this control.
FileBrowse PathBrowse ClipBrowse	The FileBrowse input allows you to browse to select a file on disk, while the PathBrowse input allows you to select a directory. ClipBrowse is used to get sequences with their appropriate filters.	Save (boolean) Set this option to true if the dialog is used to select a path or file which does not yet exist (i.e.when selecting a filae to save to)
Slider	Displays a standard Fusion slider control. Labels can be set for the high and low ends of the slider using the following options.	LowName (string) The text label used for the low (left) end of the slider. HighName (string) The text label used for the high (right) end of the slider.
Checkbox	Displays a standard Fusion checkbox control. You can display several of these controls, next to each other using the NumAcross option	Default (numeric) The default state of the checkbox, use 0 to leave the checkbox deselected, or 1 to enabled the checkbox. Defaults to 0 if not specified. NumAcross (numeric) If the NumAcross value is set, the dialog will reserve space to display two or more checkboxes next to each other. The NumAcross value must be set for all checkboxes to be displayed on the same row. See examples below for more information.

Position	Displays a pair of edit boxes used to enter X & Y coordinates for a center control or other position value. The default value of this control is a table with two values, one for the X value and one for the Y. The control returns a table of values.	Default (table {x,y}) A table with two numeric entries specifying the value for the x and y coordinates.
Screw	Displays the standard Fusion thumbnail or screw control. This control is almost identical to a slider in almost all respects except that its range is infinite, and so it is well suited for angle controls and other values without practical limits.
Dropdown	Displays the standard Fusion drop down menu for selecting from a list of options. This control exposes and option call Options, which takes a table containing the values for the drop down menu. Note that the index for the Options table starts at 0, not 1 like is common in most FusionScript tables. So, if you wish to set a default for the first entry in a list, you would use Default=0, for the second Default=1, and so on	Default (num) A number specifying the index of the options table (below) to use as a default value for the drop down box when it is created. Default (table {string, string, string…}) A table of strings describing the values displayed by the drop down box.
Multibutton	Displays a Multibutton, where each option is drawn as a button. The same options are used like in a Dropdown.	Default (num) A number specifying the index of the options table (below) to use as a default value for the drop down box when it is created. Options (table {string, string, string…}) A table of strings describing the values displayed as buttons.

This example shows a dialog that contains most of the various control types:

composition_path = composition:GetAttrs().COMPS_FileName

msg = “This dialog is only an example. It does not actually do anything, “..

“so you should not expect to see a useful result from running this script.”

= {}

d[1] = {“File”, Name = “Select A Source File”, “FileBrowse”, Default = composition_path}

d[2] = {“Path”, Name = “New Destination”, “PathBrowse” }

d[3] = {“Copies”, Name = “Number of Copies”, “Slider”, Default = 1.0, Integer = true, Min = 1, Max = 5 } d[4] = {“Angle”, Name = “Angle”, “Screw”, Default = 180, Min = 0, Max = 360}

d[5] = {“Menu”, Name = “Select One”, “Dropdown”, Options = {“Good”, “Better”, “Best”}, Default = 1} d[6] = {“Center”, Name = “Center”, “Position”, Default = {0.5, 0.5} }

d[7] = {“Invert”, Name = “Invert”, “Checkbox”, NumAcross = 2 }

d[8] = {“Save”, Name = “Save Settings”, “Checkbox”, NumAcross = 2, Default = 1 }

d[9] = {“Msg”, Name = “Warning”, “Text”, ReadOnly = true, Lines = 5, Wrap = true, Default = msg} dialog = composition:AskUser(“A Sample Dialog”, d)

if dialog == nil then

print(“You cancelled the dialog!”) else

dump(dialog)

end

Note

In Python, make sure to create a dictionary with proper indices starting with 1 as explained in the Chapter about Python. For Example:

ret = composition.AskUser(“A simple dialog”, dialog)

2: {1: “dlgDir”, “Name”: “A Check Box”, 2: “Checkbox”, “Default”: 1}}

dialog = {1: {1: “dlgDir”, “Name”: “Select a Directory”, 2: “PathBrowse”},
