Methods
FlowView.FlushSetPosQueue()
Moves all tools queued for positioning with QueueSetPos.
FlowView.FrameAll()
Rescale and reposition the FlowView to contain all tools.
FlowView.GetPos()
Returns the position of a tool.
This function returns two numeric values containing the X and Y co-ordinates of the tool. In Python use GetPosTable instead.
x, y = flow.GetPosTable(comp.Background1).values()
flow = comp.CurrentFrame.FlowView
> Python usage:
x, y = flow:GetPos(tool)
flow = comp.CurrentFrame.FlowView
> Lua usage:
> Returns: x
> Return type: number
FlowView.GetPosTable(tool)
Returns the position of a tool as a table. Use this in Python to get the X and Y value.
> Python usage:
flow = comp.CurrentFrame.FlowView
x, y = flow.GetPosTable(comp.Background1).values()
> Lua usage:
flow = comp.CurrentFrame.FlowView x, y = flow:GetPos(tool)
> Parameters:
tool (object) – tool
> Returns: pos
> Return type: table
FlowView.GetScale()
Returns the current scale of the contents.
This function returns a numeric value indicating the current scale of the FlowView. 1 means 100%, while 0.1 means 10% of the default scale.
> Returns: scale
> Return type: number
FlowView.QueueSetPos(tool, x, y)
Queues the moving of a tool to a new position.
All queued moves will be evaluated once FlushSetPosQueue() has been called.
> Parameters:
tool (object) – tool
x (number) – x
y (number) – y
FlowView.Select(tool[, select])
Selects or deselects a tool.
This function will add or remove the tool specified in it’s first argument from the current tool selection set. The second argument should be set to false to remove the tool from the selection, or to true to add it.
tool should contain the tool that will be selected or deselected in the FlowView.
select setting this to false will deselect the tool specified in the first argument. Otherwise the default value of true is used, which selects the tool.
If called with no arguments, the function will clear all tools from the current selection.
> Parameters:
tool (object) – tool
select (boolean) – select
FlowView.SetPos(tool, x, y)
Moves a tool to a new position.
> Python usage:
# Align all selected tools to x co-ordinate of the ActiveTool
flow = comp.CurrentFrame.FlowView
x, y = flow.GetPosTable(comp.ActiveTool) for t in comp.GetToolList(True).values():
cur_x, cur_y = flow.GetPosTable(t) flow.SetPos(t, x, cur_y)
local x, y = flow:GetPos(comp.ActiveTool)
local flow = comp.CurrentFrame.FlowView
-- Align all selected tools to x co-ordinate of the ActiveTool
> Lua usage:
for i, t in pairs(comp:GetToolList(true)) do cur_x, cur_y = flow:GetPos(t) flow:SetPos(t, x, cur_y)
end
tool (object) – tool
x (number) – x
y (number) – y
FlowView.SetScale(scale)
Change the scale of the contents.
This function rescales the FlowView to the amount specified. A value of 1 for the scale argument would set the FlowView to 100%, while a value of 0.1 would set it to 10% of the default scale.
> Parameters:
scale (number) – scale
